tailscale

• tailscale/tailscale
  • BSD-3, Go
  • taildrop
    • 类似 Airdrop 能力
• 可使用 headscale 提供控制服务
• 参考
  • WireGuard vs. Tailscale
  • Tailscale CLI
  • 价格
    • Free - 1 User, 1 Admin, 1 ACL, 20 Devices, 1 Subnet routers
    • Team - 60$/User/Year - 5/Devices/User, 5 Subnet routers, 2 Admin, 5 Users in ACL
  • k8s
  • tailscale-ssh
• DNS 100.100.100.100

警告

• 一次只能加入一个网络
  • log into multiple tailscale accounts #713
  • support connecting to multiple networks #183
• Linux 下使用的 用户空间 wg 实现 - 性能弱于 wg
  • Kernel implementation of tstun #3264
  • Linux kernel Wireguard data plane #426
• macOS GUI, iOS, Android 不支持修改 control server
  • 只有命令行才可以修改 control server
• IP 一旦分配不可修改 - IP 只能自动分配 - How Tailscale assigns IP addresses
  • 移除节点 - 重新加入
  • 清除 tailscale 状态
  • 固定 100.64.0.0/10 - CGNAT - RFC6598
• Custom records in MagicDNS #1543
• Open source server #498
• Tailscale in browser #3157

# macOS
brew install tailscale
# Golang
go install tailscale.com/cmd/tailscale{,d}@latest
# AlpineLinux
apk add tailscale

# Binary https://pkgs.tailscale.com/stable/#static
# 内置 systemd service, 没有 openrc
curl -O https://pkgs.tailscale.com/stable/tailscale_1.38.1_amd64.tgz
tar zxvf tailscale_*.tgz

tailscale up --login-server http://192.168.1.2:8080

tailscale down

tailscale ip
# 下次 up 需要重新授权
tailscale logout
# 网络状况
tailscale netcheck

tailscale ping host
tailscale status
tailscale web

tailscale up	default	note
--accept-dns	true	修改本地 DNS 为 100.100.100.100
--accept-routes	false	接受服务端配置的路由
--advertise-exit-node
--advertise-routes <ip>		申请路由到该节点
--advertise-tags <tags>
--authkey <key>
--exit-node <ip>		指定出口节点
--force-reauth
--host-routes
--hostname <name>
--operator <user>
--qr
--reset
--shields-up

tailscaled

go install tailscale.com/cmd/tailscale{,d}@latest
# macOS
sudo tailscaled install-system-daemon

flag	default	for
-bird-socket string		path of the bird unix socket
-debug [ip]:port		listen debug server
-outbound-http-proxy-listen [ip]:port		outbound HTTP proxy
-cleanup		clean up system state and exit
-port value	0	UDP port for WireGuard and peer-to-peer traffic - 0 auto
-socket string	/var/run/tailscaled.socket	path of the service unix socket
-socks5-server [ip]:port		SOCK5 server
-state string	<statedir>/tailscaled.state	state file
-statedir string		path of config state, TLS certs, temporary incoming Taildrop files
-tun string	utun	userspace-networking 用户空间
-verbose int	0

• -state - $HOME/.local/share/tailscale/tailscaled.state
  • kube:<secret-name>
  • arn:aws:ssm:... - AWS SSM
  • mem:
• -debug
  • /debug/metrics
• -port 41641

debug

debug	for
derp-map	DERP 列表
daemon-goroutines	goroutines
metrics	metrics
env	cmd/tailscale environment
hostinfo	hostinfo
local-creds	print how to access Tailscale local API
restun	force a magicsock restun
rebind	force a magicsock rebind
prefs	print prefs
watch-ipn	subscribe to IPN message bus

tailscale version

tailscale netcheck
tailscale status
tailscale derp-map

Notes

• 记录的 JSON 状态
  • /var/lib/tailscale/tailscaled.state
    • _daemon
    • _machinekey
• DNS
  • 修改 /etc/resolv.conf
  • 备份之前配置 /etc/resolv.pre-tailscale-backup.conf
• DERP - Encrypted TCP relays

sudo jq -r ._daemon /var/lib/tailscale/tailscaled.state | base64 -d | jq

tailscaled.state

{
  "ControlURL": "",
  "RouteAll": false,
  "AllowSingleHosts": true,
  "ExitNodeID": "",
  "ExitNodeIP": "",
  "ExitNodeAllowLANAccess": false,
  "CorpDNS": false,
  "WantRunning": true,
  "LoggedOut": false,
  "ShieldsUp": false,
  "AdvertiseTags": ["tag:linux"],
  "Hostname": "",
  "NotepadURLs": false,
  "AdvertiseRoutes": ["192.168.1.0/22"],
  "NoSNAT": false,
  "NetfilterMode": 2,
  "Config": {
    "PrivateMachineKey": "privkey:",
    "PrivateNodeKey": "privkey:",
    "OldPrivateNodeKey": "privkey:",
    "Provider": "",
    "LoginName": "truth"
  }
}

AdvertiseRoutes

-A POSTROUTING -j ts-postrouting
-A INPUT -j ts-input
-A FORWARD -j ts-forward

-A ts-postrouting -m mark --mark 0x40000 -j MASQUERADE

-A ts-forward -i tailscale0 -j MARK --set-xmark 0x40000/0xffffffff
-A ts-forward -m mark --mark 0x40000 -j ACCEPT
# 不 forward 内部
-A ts-forward -s 100.64.0.0/10 -o tailscale0 -j DROP
-A ts-forward -o tailscale0 -j ACCEPT
# 当前节点
-A ts-input -s 100.64.0.8/32 -i lo -j ACCEPT
-A ts-input -s 100.115.92.0/23 ! -i tailscale0 -j RETURN
-A ts-input -s 100.64.0.0/10 ! -i tailscale0 -j DROP

derp

• zouyq/derper
• 80, 443, 3478
  • HTTPS + STUN
• 与 tailscaled 一同部署可达到限制访问的目的 - Auth
• Custom DERP Servers

# 默认 DERP
curl -s https://controlplane.tailscale.com/derpmap/default | jq

# 安装
go install tailscale.com/cmd/derper@main
# macOS 交叉编译
# GOOS=linux go build -trimpath -o bin/derper ./cmd/derper
# GOOS=linux go build -trimpath -o bin/tailscale ./cmd/tailscale
# GOOS=linux go build -trimpath -o bin/tailscaled ./cmd/tailscaled

# 启动
derper --hostname=your-hostname.com
# 启动 - 通过本地 tailscaled 验证客户端
sudo derper --hostname=your-hostname.com --verify-clients
# behind proxy
# 需要修改代码: 启用 tls 关闭 debug
# -a 如果指定地址会同时用于 http 和 stun-port
sudo derper --hostname derper.example.com --verify-clients -a :28443 -http-port 28080

flag	default	for
-a [ip]:port	:443	HTTPS listen address
-accept-connection-burst	9223372036854775807	burst limit for accepting new connection
-accept-connection-limit	+Inf	rate limit for accepting new connection
-bootstrap-dns-names string		optional comma-separated list of hostnames to make available at /bootstrap-dns
-c string		配置目录
-certdir string	$HOME/.cache/tailscale/derper-certs	letsencrypt 证书目录
-certmode string	letsencrypt	manual, letsencrypt
-dev		开发模式
-hostname string	derp.tailscale.com	LetsEncrypt host name
-http-port int	80	-1 禁用
-logcollection string		logtail collection to log to
-mesh-psk-file string		mesh pre-shared key file - hex string
-mesh-with string		optional comma-separated list of hostnames to mesh with; the server's own hostname can be in the list
-stun	true	运行 STUN server
-stun-port int	3478
-verify-clients	false	通过本地 tailscaled 验证客户端

verify-clients

• tailscale sttaus 里的节点才能使用 derp - 否则会验证失败
• 可以考虑 derp 节点能看到所有其他节点
  • { Action: accept, Users: [ tag:derp ], Ports: [ "*:*" ] }
• hostname 为访问 derp 的 域名 而不是 login-server 域名
• port 为 443 才会启用 tls - tsweb.IsProd443(*addr) || *certMode == "manual"

openrc

#!/sbin/openrc-run
supervisor=supervise-daemon

name="Tailscale Derper"
description="Derper relay."

command=/usr/local/bin/derper
# config
command_args="--hostname derp.example.com --verify-clients -a :443 -http-port 8080"

DERPER_LOGFILE="${DERPER_LOGFILE:-/var/log/${RC_SVCNAME}.log}"
output_log=${DERPER_LOGFILE}
error_log=${DERPER_LOGFILE}

depend() {
  use logger dns tailscale
  need net
}

Taildrop

# 发送
# tailscale file cp <files> <name-or-ip>:
# 接收
tailscale file get .

NAT

• https://tailscale.com/blog/how-nat-traversal-works/
  • HN

Glossary

• Exit Node
  • 路由所有流量 - 类似传统 VPN 方式 - 0.0.0.0/0
  • tailscale up --advertise-exit-node 允许节点作为 Exit Node
  • 会添加 tag - 通过 is:exit-node 过滤
  • tailscale up --exit-node=<exit-node-ip> 客户端选择 Exit Node
• MagicDNS
  • 可以使用 hostname 访问设备
  • 还会添加 search domain 通过 网址域名访问
  • 可通过 --accept-dns=false 关闭
• Subnet Route
  • 作为网关桥接不同网络
  • --advertise-routes
  • ACL 控制 { "action": "accept", "users": ["*"], "ports": ["172.20.10.0/24:*",] }

echo 'net.ipv4.ip_forward = 1' | sudo tee -a /etc/sysctl.conf
echo 'net.ipv6.conf.all.forwarding = 1' | sudo tee -a /etc/sysctl.conf
sudo sysctl -p /etc/sysctl.conf

• IPN - Identified Private Network
• 用户空间网络
  • 使用 socks5 或 http 代理 访问网络
  • tailscaled --tun=userspace-networking --socks5-server=localhost:1055
  • 主要用于 serverless、容器、权限不足、不支持 tun 设备 等场景
  • Userspace networking mode

FAQ

derphttp.Client.Recv connect to region 999: tls: first record does not look like a TLS handshake

检查 derper 是否启用 TLS 是否申请证书。

derper 只有在端口为 443 时才会申请 letsencrypt 证书。

not connected to home DERP region 999

自定义的 DERP 确保能被访问，HTTP、HTTPS、STUN

tsweb.AllowDebugAccess

默认允许访问 debug 的逻辑

if tsaddr.IsTailscaleIP(ip) || ip.IsLoopback() || ipStr == envknob.String("TS_ALLOW_DEBUG_IP") {
  return true
}

如果使用了反向代理(例如: derper) 会导致检测失败。

not logged in, last login error=fetch control key: 530

检查 login server 是不是异常了
