HPA

HPA

caution
  • 资源使用率基于 requests 计算,而不是 limits
API VersionK8S说明
autoscaling/v11.1+仅支持 CPU,targetCPUUtilizationPercentage
autoscaling/v2beta11.12+支持多指标
autoscaling/v2beta21.16+增加 behavior 配置
autoscaling/v21.23+正式版,推荐使用
  • v1.16 后允许 minReplicas=0
  • https://kubernetes.io/docs/reference/generated/kubernetes-api/v1.27/#horizontalpodautoscaler-v2-autoscaling
  • metrics
    • type
      • ContainerResource:针对特定容器的资源(如 CPU、内存)进行伸缩,适用于多容器 Pod 场景。
      • Resource:根据 Pod 整体资源(如 CPU、内存)利用率进行伸缩,是最常用的类型。
      • Pods:根据每个 Pod 的自定义指标(如请求数、队列长度)进行伸缩,需在 Pod 内暴露指标。
      • Object:根据其他 Kubernetes 对象的指标(如 Service 的 QPS)进行伸缩,需配置指标来源对象。
      • External:根据集群外部系统的指标(如云服务监控、第三方 API)进行伸缩,需配置外部指标源。
    • containerResource
      • 可以选择目标 container
    • resource
  • target
    • type - Utilization, Value, AverageValue
    • averageUtilization - 所有 Pod - 只能 Resource
    • averageValue
  • behavior - scaleDown, scaleUp
    • policies
      • type: Pods
      • value - 每次变化的 Pod 数量
      • periodSeconds - 间隔
        • 0-1800
    • selectPolicy=Max
    • stabilizationWindowSeconds
      • 0-3600
      • up 默认 0
      • down 默认 300 - 5 分钟
    • 表述
      • 扩容: 等待0秒立即响应,每次扩容1个Pod,然后等待2分钟再次评估
      • 缩容: 等待5分钟确认负载下降,每次缩容1个Pod,然后等待2分钟再次评估
apiVersion: autoscaling/v2
kind: HorizontalPodAutoscaler
metadata:
name: server
spec:
scaleTargetRef:
apiVersion: apps/v1
kind: Deployment
name: server
minReplicas: 2
maxReplicas: 10
metrics:
- type: Resource # Resource、Pods、Object、External
resource:
name: cpu
target:
type: Utilization
averageUtilization: 50
desiredReplicas = ceil[currentReplicas * ( currentMetricValue / desiredMetricValue )]
